HYDROKIT
BUFFER TANK FOR HEATING & COOLING
Buffer tank for heating and cooling,
compatible with all brands of heat pumps.
BUFFER TANK FOR HEATING & COOLING
COMPATIBLE WITH ALL BRANDS OF HEAT PUMPS.
ENERGIE buffer tanks store thermal energy, in the form of hot or cold water,
for heating and cooling systems using heat pumps. This helps heat pumps
operate less frequently, leading to lower energy consumption and reduced
costs. Buffer tanks also provide a readily available reserve of hot or cold
water, resulting in more consistent comfort and potentially extending the
lifespan of your heat pump.
Energie buffer tanks come pre-integrated with key components like pumps,
valves, and expansion vessel, streamlining the installation process and saving
installers up to 20% of their time.
- 100 litre stainless steel tank
- 10 litre expansion vessel
- Grundfos circulation pump
- Caleffi Technopolymer instrument holder collector
- Safety valve
- Purge Valve
- Pressure gauge
- Immersion thermostat
- Wall-mounted installation (optional)
- 1″ shut-off valves
- ½” drain valve
- High Density Polyurethane Thermal Insulation
| TECHNICAL DATA | HYDROKIT 100L |
| Nominal Capacity | L | 100 |
| Cylinder dimensions | mm | Ø500x1000 |
| Max working pressure cylinder | Bar | 6 |
| Max running temperature cylinder | °C | 80 |
| Thermal insulation | W/m.k | 0,025 |
| Insulation density | kg/m3 | 46 |
| Static heat losses | W | 35 |
| Energy efficiency class | - | A |
| Net weight | Kg | 33 |
| Insulation (Thickness) | mm | 60 |
| Circulator flow (H1)= 7,5m(H2)= 5,5m(H3)= 3m | m3/h | (H1)-1,0(H2)-1,9(H3)-3,0 |
| Hydraulic connections | Pol | 1” |
